Heated hoses are specialized flexible assemblies designed to maintain the temperature of fluids or gases as they are transferred from one point to another. Built with internal heating elements, these hoses prevent heat loss, condensation, or freezing—making them essential for applications requiring temperature consistency over distance.
Our heated hoses deliver precise, reliable heating performance while remaining flexible and durable, ensuring smooth operation across a wide range of industries.
Built-in heating element ensures precise temperature control along the entire hose.
Designed to bend and move without damaging the heating element.
Available with integrated sensors and controllers for adjustable heat levels.
Outer jackets made from high-TENSILE STELL WIRE
Thermoplastic inner tube (nylon, PTFE, or polyurethane), reinforced with multiple spiral layers of high-tensile steel wire, and integrated with a Ni/Cr heating element with proper insulation.
Easy to install with quick-connect fittings and termination options.
Transfer of viscous or temperature-sensitive fluids.
Adhesive dispensing (hot melt glue, resin, etc.).
Maintains chocolate, oil, syrup lines at optimal flow temperature.
Safe transfer of sensitive fluids in chemical and pharmaceutical industries.
Rubber and plastic extrusion processes.
| Parameter | Specification |
|---|---|
| Operating Voltage | 12V to 240V AC or DC |
| Temperature Range | Ambient to 200°C or higher (custom) |
| Hose Diameter | ¼" to 2" (or custom sizes) |
| Length Range | 0.5m to 20m (customizable) |
| Outer Jacket Options | Silicone, Polyamide, or PTFE |
| Heating Element Type | Resistance wire or self-regulating cable |
| Sensor Integration | Optional thermocouple or RTD sensor |
| Power Output | 20 to 150 W/m (based on application) |
| Connector Type | Standard, quick-connect, or custom |
We manufacture heated hoses in various diameters, lengths, temperature ratings, and electrical configurations. Custom-built solutions are available for high-pressure, sterile, or hazardous fluid applications.
